Transparent Plastic Injection Mold 1 - 8 Cavities Metal Insert Moulding For Optical Parts ±0.01mm Precision
-
Highlight
Transparent Plastic Injection Mold
,1 Cavity Metal Insert Moulding
,8 Cavities Metal Insert Moulding
-
Product NamePlastic Injection Mold
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Transparent Plastic Injection Mold 1 - 8 Cavities Metal Insert Moulding For Optical Parts ±0.01mm Precision
Transparent Plastic Injection Mold for Optical Parts ±0.01mm Precision
A high-quality solution for highly transparent parts requiring precision bonding between transparent materials and metal inserts.
Product Process
The insert injection mold utilizes precision machining and mirror polishing to achieve a flawless bond between the transparent part and the metal insert. This solution is widely used in transparent products requiring the most demanding appearance.
Process Flow
- Analysis and Design of Transparent Parts
- CAD Simulation of Melt Flow and Optical Properties
- CNC Precision Machining and Mirror Polishing
- Mold Assembly and Cooling Optimization
- Test Molds to Check Transparency and Bonding
Product Specifications
| Item | Parameter | Description |
|---|---|---|
| Mold Type | Transparent Insert Injection Mold | |
| Mold Material | S136 420 | |
| Number of Cavities | 1–8 | |
| Mold Life | 600,000–1,000,000 Cycles | |
| Surface Treatment | Mirror Polishing | |
| Applicable Materials | PMMA, PC, PET | |
| Insert Type | Metal, Optical | |
| Product Accuracy | ±0.01mm | |
| Cooling System | Precision Water Cooling | |
| Product Cycle | 50–75 Days |
Product Applications
- LED Lenses
- Transparent Medical Parts
- High-End Packaging Products
Product Advantages
- High Transparency, No Flow Marks
- Tight Bond between Insert and Transparent Part
- Meets Optical and Aesthetic Requirements
FAQ
Q1: Does it support optical part production?
A1: Yes, commonly seen in lenses and lampshades.
Q2: Is the mold prone to bubbles?
A2: Professional exhaust design can avoid this.
Q3: Can high precision be guaranteed?
A3: Accuracy up to ±0.01mm
Q4: Does the product easily yellow?
A4: Weather-resistant materials are used to prevent discoloration.
Customized Service
We can customize high-gloss mold solutions based on your transparent part and optical requirements.
Related Cases
Our services cover all industries and reach all parts of the world.
