Transparent Plastic Prototype Molds 100K - 200K Shots Mirror Polished Rapid Injection Mold Tooling
-
Highlight
Transparent Plastic Prototype Molds
,Mirror Polished Prototype Molds
,Mirror Polished Rapid Injection Mold Tooling
-
ProductPrototype Molds
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
CavityMulti Cavity,as Per Client's Requirement
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Transparent Plastic Prototype Molds 100K - 200K Shots Mirror Polished Rapid Injection Mold Tooling
Transparent Plastic Prototype Mold 100K-200K Shots Mirror Polished
Product Processing
This prototype mold is specifically engineered for transparent parts, featuring mirror polishing and high-precision machining to ensure optimal sample transparency and surface quality. Ideal for R&D and verification of optical and exterior components.
Process Flow
- Customer Transparent Part Design Confirmation
- Mold Flow Simulation Analysis
- CNC Finishing and Mirror Polishing
- Mold Assembly and Commissioning
- Mold Trial and Transparency Testing
Product Specifications
| Item | Parameter Description |
|---|---|
| Mold Type | Transparent Part Prototype |
| Mold Material | S136H NAK80 |
| Cavities | Single |
| Mold Life | 100,000–200,000 Molds |
| Part Accuracy | ±0.02mm |
| Surface Treatment | Mirror Polishing |
| Applicable Materials | PC, PMMA |
| Cooling System | High-Efficiency Cooling |
| Hot Runner System | Configurable |
| Production Cycle | 15–22 Days |
Product Applications
- Transparent Appearance Parts
- Optical Test Samples
- Lamp and Lens Part Verification
- Market Display Samples
Product Advantages
- Mirror Polishing Ensures Transparency
- High Accuracy: ±0.02mm
- Moderate Mold Life: Reusable
- Surface Quality Approaching Production Standards
- Suitable for Optical and Appearance Part Testing
FAQ
Q1: Can Transparency Be Guaranteed?
A1: Yes, Mirror Polishing Can Be Used
Q2: What is the turnaround time?
A2: 15–22 days
Q3: Is it suitable for PC and PMMA?
A3: Yes, it supports common transparent materials.
Q4: What is the mold lifespan?
A4: 100,000–200,000 molds.
Q5: Can it be mass-produced?
A5: Primarily for R&D purposes. See the mass production plan for reference.
Customized Services
- Mirror polishing and optical processing available.
- Hot runner configuration available for enhanced transparency.
- Process optimization for transparent materials.
- Meeting optical and exterior design requirements.
Related Cases
Our services cover all industries and reach all parts of the world.
