High Accuracy Auto Plastic Mould Multi Cavity Injection Plastic Mold Durable
-
Highlight
High Accuracy Auto Plastic Mould
,Multi Cavity Injection Plastic Mold
,Injection Plastic Mold Durable
-
ProductAuto Plastic Mould
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
CavityMulti Cavity,as Per Client's Requirement
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
High Accuracy Auto Plastic Mould Multi Cavity Injection Plastic Mold Durable
Precision Injection Molds For Automotive Parts Durable High Performance Tooling Solutions
Product Technology
Automotive precision molds utilize high-precision mold flow analysis and complex structural optimization to ensure finished products meet the high standards of automotive components in dimensional accuracy, strength, and appearance. High-speed CNC, wire-cut, and five-axis machining technologies ensure the complexity and smoothness of mold cavities.
Process Flow
- Product Function and Durability Requirements Analysis
- Mold Flow Simulation and Molding Process Optimization
- High-Speed CNC Rough Machining and Wire-Tap Finishing
- Mold Assembly and Trial Mold Debugging
- Performance Verification and Customer Confirmation
Product Specifications
| Item | Parameter Description |
|---|---|
| Mold Type | Precision Injection Mold for Automotive Parts |
| Mold Material | P20 H13 1.2738 |
| Number of Cavities | 2–12 |
| Mold Life | 600,000–1.2 Million Molds |
| Part Accuracy | ±0.02mm |
| Surface Treatment | Polishing, Nitriding, DLC Coating |
| Applicable Materials | PC, ABS, PBT, PA, GF |
| Cooling System | Modular Cooling Channels for Efficient Heat Dissipation |
| Hot Runner System | Single-Point or Multi-Point Hot Runners |
| Product Cycle | 50–70 Days |
Product Applications
- Automotive Center Consoles and Buttons
- Exterior Trims: Grilles and Decorative Strips
- Electrical Control Box Housings
- Precision Clips and Fixings
Product Advantages
- Mold Accuracy: ±0.02mm, Meeting Precision Assembly Requirements
- DLC Coating improves mold wear and corrosion resistance
- Supports multi-cavity molds, increasing production capacity and reducing costs
- Cooling system efficiently dissipates heat and shortens molding cycles
- Meets the appearance and structural strength requirements of automotive parts
FAQ
Q1: Can the mold be used for high-gloss parts?
A1: Yes. We offer mirror polishing and surface treatment to meet appearance requirements.
Q2: Does it support multi-cavity molds?
A2: Yes. We can design the number of cavities based on customer production requirements.
Q3: What is the typical mold lifespan?
A3: Typical lifespan is 600,000–1.2 million cycles, which can be increased based on steel material selection.
Q4: Can the mold be compatible with a hot runner system?
A4: Yes. Single-point or multi-point hot runners are available, depending on the part structure.
Q5: Mold delivery time?
A5: Typical: 50–70 days. Expedited service available.
Customized Service
- Mold structure and cavity number can be customized based on automotive part requirements
- Various surface treatments available. Suitable for both exterior and structural parts
- Configurable with automated part handling and robotic interfaces
- Optical-grade polishing and coating solutions for high-gloss parts
