Polishing Precision Injection Mould 1 - 20 Cavities Customized Injection Moulds 800K Shots
-
Highlight
Polishing Precision Injection Mould
,1 Cavities Customized Injection Moulds
,20 Cavities Customized Injection Moulds
-
ProductPrecision Injection Mould
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
CavityMulti Cavity,as Per Client's Requirement
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Polishing Precision Injection Mould 1 - 20 Cavities Customized Injection Moulds 800K Shots
Precision Plastic Injection Mold 1-20 Cavities 800K Shots
Product Technology
Precision Plastic Molds utilizes strict design specifications and high-end processing equipment to ensure mold stability during high-volume production. Suitable for complex plastic parts and products requiring high surface quality.
Process Flow
- Customer Needs Assessment
- CAE Analysis of Gates and Runners
- High-Speed Machining and EDM
- Mold Assembly and Cooling Design
- Mold Trial Inspection and Optimization
Product Specifications
| Item | Parameter Description |
|---|---|
| Mold Type | Precision Injection Mold |
| Mold Material | 718H S136 H13 |
| Cavities | 1-20 |
| Mold Life | 800,000-1.2 Million Molds |
| Part Accuracy | ±0.01-0.02mm |
| Surface Treatment | Polishing, Nitriding, Electroplating |
| Applicable Materials | ABS PC PBT PPS |
| Cooling System | Independent High-Efficiency Cooling |
| Heat Treatment | Vacuum Heat Treatment |
| Production Cycle | 50-70 Days |
Product Applications
- Products with High Surface Requirements
- Precision Functional Parts
- Long-Term Mass Production
Product Advantages
- Accuracy ±0.01-0.02mm
- Life Up to Millions of Molds
- Efficient Cooling System
- Good Stability and Consistency
FAQ
Q1: Is this mold suitable for transparent parts?
A1: Yes. Surface treatment can achieve mirror-like finish.
Q2: What is the mold lifespan?
A2: 800,000-1.2 million molds.
Q3: Mold delivery time.
A3: Typically 50-70 days.
Q4: Is it suitable for engineering plastics?
A4: It supports PC, PPS, and PBT.
Q5: Does it support multiple cavities?
A5: Customization with 1-20 cavities is available.
Personalized Customization Services: Customization of cooling system, number of cavities, and surface treatment is available.
