Highlight
1-16 cavity plastic injection molds
,high precision plastic molds ±0.01mm
,multi-cavity injection molds with warranty
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
CavityMulti Cavity,as Per Client's Requirement
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Precision Plastic Injection Molds 1-16 Cavity ±0.01mm Accuracy
Premium Precision Plastic Molds for Injection Molding
High Accuracy and Long Life
Product Technology
Precision plastic molds utilize advanced manufacturing techniques, combining high-strength steel with heat treatment processes to ensure mold stability and high precision over long-term production. They are widely used in molding products that meet stringent quality standards.
Process Flow
- Product Requirements Confirmation and Design Evaluation
- CAE Analysis and Optimization of Gate and Cooling Systems
- CNC and Spark EDM High-Precision Machining
- Mold Assembly and Functional Debugging
- Mold Trial and Performance Verification
Product Specifications
| Item | Parameter Description |
|---|---|
| Mold Type | Precision Injection Mold |
| Mold Material | 718H / H13 / S136 |
| Cavity | 1–16 |
| Mold Life | 800,000–1.5 Million Cycles |
| Part Accuracy | ±0.01mm |
| Surface Treatment | Mirror Polishing / Nitriding / PVD |
| Applicable Materials | ABS / PC / PPS / POM |
| Cooling System | High-Efficiency Cooling Circulation System |
| Heat Treatment Process | Vacuum Heat Treatment |
| Production Cycle | 45–70 Days |
Product Applications
- High-Precision Plastic Parts Production
- Injection Molding of Stringent Appearance Parts
- Small-Batch Trial and Large-Scale Production
Product Advantages
- Ultra-High Precision ±0.01mm
- Mold Life Up to 1.5 Million Cycles
- Stable and Consistent Molding
- Efficient Production and Cost Savings
FAQ
Q1: What is the mold's maximum precision?
A1: ±0.01mm
Q2: Does it support complex structures?
A2: Yes. Complex sliders and multi-cavity molds can be customized.
Q3: What is the typical mold lifespan?
A3: 800,000–1.5 million mold cycles
Q4: What plastics are suitable?
A4: Engineering plastics such as ABS, PC, PPS, and POM
Q5: Is mold testing provided?
A5: Yes. A complete mold test will be conducted and a report will be issued before delivery.
Personalized Customization Service
We support customization of multi-cavity molds, special structures, and hot runner systems to ensure optimal production performance for different application scenarios.
