Custom Made Unscrewing Injection Molds for Precision Threaded Components Automatic and Efficient
-
Highlight
custom unscrewing injection molds
,threaded parts injection molds
,1-6 cavities unscrewing molds
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
CavityMulti Cavity,as Per Client's Requirement
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
Product NamePlastic Injection Mould,injection Machine Mold,Shanghai Factory Cheap Plastic Component Injection Mold,High Quality Virgin Raw Material Custom Plastic Injection Mold Product,Gear Parts
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Custom Made Unscrewing Injection Molds for Precision Threaded Components Automatic and Efficient
Custom Made Unscrewing Injection Molds for Precision Threaded Components
Automatic and Efficient Threaded Part Production
Our unscrewing molds utilize servo or hydraulic drives to automatically rotate the core after injection molding, ensuring smooth demolding of threaded parts while preventing damage from forced ejection.
Process Flow
- Thread Modeling and Mold Design
- CAE Verification of Rotating Mechanism Movement
- CNC Finishing and Heat Treatment
- Installation of Servo Drive
- Test Mold to Check Thread Accuracy
Product Specifications
| Item | Parameter Description |
|---|---|
| Mold Type | Threaded Unscrew Mold |
| Mold Material | P20 / S136 / H13 |
| Number of Cavities | 1–6 |
| Thread Diameter | M5–M60 |
| Mold Life | 700,000–1.3 Million Molds |
| Mold Release Method | Automatic Rotation |
| Product Accuracy | ±0.03mm |
| Cooling System | Independent Cooling Water Circuit |
| Drive Method | Hydraulic / Motor / Servo |
| Production Cycle | 45–70 Days |
Product Applications
- Suitable for small or large-batch production of threaded parts
- Ideal for products requiring high precision and consistency
- Applicable to a wide range of plastic processing projects
Product Advantages
- Prevents thread damage during demolding
- High automated production efficiency
- Multiple drive options available
- Extended mold service life
Frequently Asked Questions
Q1: Does it support multiple cavities?
A1: Yes. We offer designs with 1–6 cavities based on customer needs.
Q2: Is it suitable for mass production?
A2: Yes. Automatic rotary demolding is optimized for mass production.
Q3: What is the thread accuracy controllable?
A3: Precision control up to ±0.02–0.03mm.
Q4: Is the mold easy to maintain?
A4: Yes. The compact structure makes maintenance simple.
Q5: Can you provide samples?
A5: Yes. Samples will be provided for confirmation before delivery.
Customized Service
We customize thread diameter, number of cavities, and drive method to meet specific production requirements. Our solutions include fast prototyping and scalable mass production capabilities.
