High Efficiency Multi Cavity Tooling Precision Plastic Packaging Mould
-
Highlight
High Efficiency Multi Cavity Tooling
,Precision Plastic Packaging Mould
,Plastic Packaging Mould High Efficiency
-
Product NameMulti Cavity Tooling
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
High Efficiency Multi Cavity Tooling Precision Plastic Packaging Mould
Multi Cavity Injection Molds High Efficiency Mass Production For Food Packaging And Medical Parts
Fast Cycle Time and Cost Effective Plastic Manufacturing
Product Technology
Multi-cavity molds evenly distribute cavities, improving injection molding machine utilization and making them suitable for high-volume, fast-paced production scenarios.
Process Flow
- Product Structure and Cavity Analysis
- CAD/CAE Flow and Cooling Simulation
- High-Speed CNC Cavity Machining
- Assembly and Guide Positioning Calibration
- Mold Trial Verification for Productivity and Stability
Product Specifications
| Item | Parameter | Description |
|---|---|---|
| Mold Type | Multi-Cavity Injection Mold | |
| Mold Material | P20 H13 | |
| Cavities | 4–32 | |
| Mold Life | 600,000–1.2 Million Cycles | |
| Surface Treatment | Polishing Chrome Plating | |
| Applicable Materials | PP, ABS, PA, PC | |
| Precision Tolerance | ±0.02mm | |
| Cooling System | High-Efficiency Water Cooling | |
| Injection Molding Machine Compatibility | 200T–800T | |
| Production Cycle | 50–70 Days |
Product Applications
- Bottle Caps
- Small Toys
- Industrial Accessories
Product Advantages
- Significantly Increased Productivity
- Reduced Unit Cost
- Ensures Stable Mold Operation
- Easy to Scale
FAQ
Q1: Can Different Parts Be Produced in a Multi-Cavity Mold?
A1: Generally Not Recommended. Similar Parts Recommended.
Q2: What happens if the part weight is uneven?
A2: Adjustments to the gate and runner design are required.
Q3: Can multi-cavity molds be used with robots?
A3: Yes, they are suitable for fully automated production.
Q4: Is fast delivery supported?
A4: Yes, we offer expedited design and processing.
Q5: Will the cooling system affect efficiency?
A5: Efficient cooling design can shorten cycle time.
Customized Services
We can design the number of cavities and cooling solutions based on customer needs to optimize production efficiency.
