Chrome Plating Multi Cavity Molds 8 Cavities - 48 Cavities Bottle Cap Mould For Packaging Medical Parts
-
Highlight
Chrome Plating Multi Cavity Molds
,8 Cavities Bottle Cap Mould
,48 Cavities Bottle Cap Mould
-
Product NameMulti Cavity Molds
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Chrome Plating Multi Cavity Molds 8 Cavities - 48 Cavities Bottle Cap Mould For Packaging Medical Parts
Multi Cavity Plastic Injection Mold 8-48 Cavities for Packaging Medical Parts
Designed for packaging and medical parts manufacturing, our multi-cavity plastic injection molds enable simultaneous molding of multiple parts, significantly increasing production output while maintaining precision and consistency.
Product Technology
Multi-cavity plastic injection molds incorporate multiple cavities within a single mold structure, optimizing production efficiency for high-volume manufacturing of standardized components.
Process Flow
- Mold Design: CAE analysis optimizes gating systems and cavity balance
- Material Preparation: Premium wear-resistant steel selection for extended mold life
- Precision Machining: CNC and EDM processes ensure consistent cavity accuracy
- Assembly and Commissioning: Integration of guide systems and cooling channels
- Mold Trial Verification: Quality checks for product qualification and cavity uniformity
Product Specifications
| Item | Parameter Description |
|---|---|
| Mold Type | Multi-cavity plastic injection mold |
| Mold Steel | H13, S136, P20 |
| Number of Cavities | 8–48 |
| Mold Hardness | HRC30–52 |
| Surface Treatment | Polishing, Chrome Plating, Nitriding |
| Applicable Materials | PP, PE, ABS, PC |
| Mold Life | 800,000–1.2 Million Molds |
| Part Accuracy | ±0.02mm |
| Cooling System | Independent Water Cooling |
| Lead Time | 50–70 Days |
Product Applications
- Medical Consumables: Syringes, surgical instrument housings
- Packaging Containers: Food boxes, bottle caps, plastic cups
- Daily Necessities: High-volume small injection molded parts
Product Advantages
- Reduced unit costs through efficient high-volume molding
- Exceptional product consistency for medical-grade applications
- Extended mold life for stable, long-term production
- Compatibility with various injection molding machines
Frequently Asked Questions
Q1: Are multi-cavity molds suitable for small-batch production?
A1: Designed primarily for large-batch production. We recommend single-cavity molds for smaller production runs.
Q2: Does a larger number of cavities increase molding time?
A2: Cycle time remains largely unaffected, though higher-capacity injection molding machines are required.
Q3: Can transparent products be processed?
A3: Yes, with specialized optical polishing techniques for clarity.
Q4: How is consistency ensured for each cavity?
A4: Through precision-engineered gating systems and rigorous quality control during manufacturing.
Q5: Are multi-cavity molds difficult to maintain?
A5: Routine maintenance of cooling channels and guide systems ensures optimal performance.
Customized Service
We offer tailored solutions with customizable cavity counts, gate types, and dimensions to meet specific production requirements in packaging and medical applications, ensuring optimal efficiency for your manufacturing needs.
