Highlight
High Speed Multi Cavity Molds
,Surface Polishing Medical Plastic Mold
,Medical Plastic Mold High Speed
-
Product NameMulti Cavity Molds
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
High Speed Multi Cavity Molds Surface Polishing Medical Plastic Mold
Advanced Multi Cavity Plastic Molds Faster Cycle Time And Reduced Unit Cost
Product Technology
High-speed multi-cavity molds are designed for medical device consumables, utilizing high-precision cavities and a high-speed cooling system to ensure product consistency and cleanliness.
Process Flow
- Requirements Analysis and Design Based on Medical Standards
- Mold Structure Optimization Ensures Balanced Cavity Count
- High-Speed Milling and EDM Processing
- Surface Polishing and Rust Prevention
- Mold Trial Testing for Medical-Grade Precision
Product Specifications
| Item | Parameter | Description |
|---|---|---|
| Mold Type | High-Speed Multi-Cavity Mold | |
| Mold Steel | S136 H13 420SS | |
| Cavity | 16-64 | |
| Mold Life | Over 1 Million Molds | |
| Precision Tolerance | ±0.01mm | |
| Surface Treatment | Mirror Polishing Nitriding | |
| Applicable Materials | PP, PC, PMMA | |
| Cooling Method | High-Efficiency Water Cooling System | |
| Applicable Industries | Medical Consumables Manufacturing | |
| Delivery Time | 60-80 Days |
Product Applications
- Syringes
- Medical Housings
- Diagnostic Device Plastic Parts
Product Advantages
- High Precision Meets Medical-Grade Requirements
- High-Speed Molding Increases Production Capacity
- Complies with Cleanroom Requirements
- Long Service Life
FAQ
Q1: Do Medical Molds Require Additional Certification?
A1: Yes. We Provide ISO-Compliant Materials and Processes.
Q2: Can you provide a sample mold?
A2: Yes. Customers can verify the results before mass production.
Q3: Is the mold corrosion-resistant?
A3: We use S136 steel, which offers high corrosion resistance.
Q4: Is it compatible with cleanroom production?
A4: The mold can be used in cleanroom injection molding equipment.
Q5: Is mold maintenance complex?
A5: Regular cleaning and lubrication are sufficient. Easy to operate.
Customized Services
We provide customized multi-cavity molds specifically for medical applications, ensuring both precision and cleanliness.
Related Cases
Our services cover all industries and reach all parts of the world.
