Steel Multi Cavity Injection Mold
,High Volume Plastic Packaging Mold
,High Volume Multi Cavity Injection Mold
-
Product NameMulti Cavity Injection Mold
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Steel Multi Cavity Injection Mold High Volume Plastic Packaging Mold
Multi Cavity Injection Mold for High Volume Consumer Packaging
Product Process
Multi-cavity injection molds are engineered for high-volume production in the consumer packaging industry. These molds feature multiple cavities within a single mold base, enabling simultaneous production of identical parts for maximum efficiency and reduced cycle times.
Process Flow
- CAD design of cavity layout and runner system
- Material selection: wear-resistant mold steel
- CNC machining of cavity and gating system
- Precision assembly and installation of cooling water lines
- Mold trials to verify product quality and appearance
Product Specifications
| Item | Parameter | Description |
|---|---|---|
| Mold Type | Multi-cavity injection mold | |
| Mold Steel | P20 H13 420 stainless steel | |
| Number of cavities | 8–72 | |
| Mold Life | 800,000–1.3 million cycles | |
| Heat Treatment | Nitriding, Vacuum Quenching | |
| Surface Treatment | Polishing, PVD | |
| Applicable Materials | PP, PE, PS | |
| Product Accuracy | ±0.02mm | |
| Cooling System | Independent water cooling | |
| Production Cycle | 50–75 days |
Product Applications
- Food packaging
- Beverage bottle caps
- Plastic containers for daily necessities
Product Advantages
- High efficiency for mass production
- Exceptional product consistency
- Reduced per-unit manufacturing costs
- Streamlined maintenance and cleaning
Frequently Asked Questions
Q: Is this mold suitable for producing complex parts?
A: Best suited for small parts with relatively simple geometries.
Q: Do multi-cavity molds require a particularly large injection molding machine?
A: Machine requirements depend on cavity count and part weight.
Q: Can a hot runner system be used?
A: Yes, hot runner systems can significantly improve production efficiency.
Q: How should a multi-cavity mold be cleaned?
A: We recommend regular cleaning of cooling systems and cavity surfaces.
Q: Can we customize packaging sizes?
A: Yes, we offer complete customization of cavity count and dimensions.
Customized Service
We provide tailored multi-cavity mold solutions designed specifically for your product requirements and packaging needs. Our engineering team will work with you to optimize cavity layout, material selection, and production parameters for maximum efficiency.
