Highlight
High Precision Overmolding Mold
,Efficient Injection Molding Mould
,Injection Molding Mould High Precision
-
Product NameOvermolding Mold
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
High Precision Overmolding Mold Efficient Injection Molding Mould
Custom Overmolding Molds Plastic Injection High Precision Durable And Efficient
Product Process
Overmolding uses a secondary injection molding process to coat a hard substrate with a soft material, enhancing the product's slip resistance, aesthetics, and comfort. This process is ideal for manufacturing high-end plastic components.
Process Flow
- Mold Structure Design and Analysis
- Mold Flow Analysis Verifies Overmolding Effect
- CNC High-Precision Cavity Machining
- Assembly of Cooling System and Positioning Structure
- Mold Trial and Performance Testing
Product Specifications
| Item | Parameter | Description |
|---|---|---|
| Mold Type | Overmolded Injection Mold | |
| Mold Material | S136 718H H13 | |
| Number of Cavities | 2–12 | |
| Mold Life | 600,000–1.2 Million Cycles | |
| Surface Treatment | Polishing, Sandblasting, Chrome Plating | |
| Applicable Materials | PC ABS PP + TPE TPU | |
| Overmolding Method | Overmolding, Thermal Bonding | |
| Product Accuracy | ±0.02mm | |
| Cooling System | High-Efficiency Water-Cooled Parallel System | |
| Production Cycle | 50–80 Days |
Product Advantages
- Beautiful Appearance, Comfortable Handfeel
- Strong Hard-Soft Combination, Durable and Reliable
- Long Mold Life, Suitable for Mass Production
- Multi-Color and Multi-Material Overmolding Available
Frequently Asked Questions
What is the accuracy of the overmolding mold?
±0.02mm
Do you support overmolding with different colors?
Yes, we can achieve two- or multi-color solutions.
What is the typical mold lifespan?
600,000–1.2 million mold cycles.
Are overmolded products prone to cracking?
No, the molding process ensures stability.
Do you provide trial molds?
Yes, we do, to ensure customer satisfaction and continued production.
Customized Services
We offer comprehensive customization options, including mold cavity count, overmolding material, cooling design, and automation interfaces.
Related Cases
Our services cover all industries and reach all parts of the world.
