Durable Injection Molding Die Wear Resistant Plastic Die Mold Customized
-
Highlight
Durable Injection Molding Die
,Injection Molding Die Wear Resistant
,Plastic Die Mold Customized
-
Product NameInjection Molding Die
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Durable Injection Molding Die Wear Resistant Plastic Die Mold Customized
Wear Resistant Overmolding Mold High Precision Customized Plastic Injection Mold Durable
Product Process
Overmolding achieves dual-material, one-piece molding by coating a hard substrate with a soft material. This advanced process enhances product durability, comfort, and visual appeal, making it ideal for high-end plastic product manufacturing.
Process Flow
- 3D mold design with precise overmolding area division
- CAE analysis of material flow and adhesion effects
- Precision CNC and EDM cavity machining
- Mold assembly with optimized cooling system
- Trial mold optimization for perfect appearance and bond strength
Product Specifications
| Item | Parameter Description |
|---|---|
| Mold Type | Overmolded injection mold |
| Mold Material | 718H, H13, S136 |
| Number of cavities | 2–10 |
| Mold Life | 600,000–1.3 million cycles |
| Surface Treatment | Polishing, Nitriding, Sandblasting |
| Applicable Materials | ABS, PC, PP, TPE, TPU |
| Overmolding Method | Overmolding, Thermal Bonding |
| Product Accuracy | ±0.02mm |
| Cooling System | High-efficiency water cooling |
| Production Cycle | 50–80 days |
Product Advantages
- Single-step process for multi-material integration
- Enhanced non-slip, wear-resistant surface durability
- Extended mold life for long-term production
- Supports multi-color and transparent overmolding
Frequently Asked Questions
Q: Can overmolding molds be used for hard-soft combinations?
A: Yes, this is commonly used for functional products requiring both rigidity and comfort.
Q: Can the thickness of the overmolding layer be precisely controlled?
A: Yes, our mold accuracy reaches ±0.02mm for precise layer control.
Q: Does the mold support automated production?
A: Yes, our molds are fully compatible with robotic operation systems.
Q: What is the production cycle?
A: Standard production typically takes 50–80 days.
Q: Do you provide trial samples?
A: Yes, we provide trial samples for quality confirmation before mass production.
Customized Services
We offer comprehensive customization options including cavity configuration, material selection, cooling system design, and specialized overmolding effects to meet your specific production requirements.
