Advanced 2K Injection Molds Dual Shot Plastic Tooling Custom and Precise
-
Highlight
2K injection mold H13 steel
,automotive parts injection mold
,650K cycles injection mold
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
Product NamePlastic Injection Mould,injection Machine Mold,Shanghai Factory Cheap Plastic Component Injection Mold,High Quality Virgin Raw Material Custom Plastic Injection Mold Product,Gear Parts
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Advanced 2K Injection Molds Dual Shot Plastic Tooling Custom and Precise
Advanced 2K Injection Molds Dual Shot Plastic Tooling Custom and Precise
Product Process
2K injection molds utilize a two-shot injection molding process to create products with multi-color appearance and functionality, making them suitable for projects with stringent requirements for both appearance and structure.
Process Flow
- Design of two-color areas and parting structure
- CAE analysis of melt bonding and venting
- CNC machining and mold detail polishing
- Mold assembly and cooling water line installation
- Test mold to verify the two-color fusion effect
Product Specifications
| Item | Parameter | Description |
|---|---|---|
| Mold Type | 2K Injection Mold | |
| Mold Material | H13 718H S136 | |
| Number of Cavities | 2–8 | |
| Mold Life | 650,000–1.15 million cycles | |
| Surface Treatment | Polishing, Sandblasting, Chrome Plating | |
| Applicable Materials | ABS PC PA + TPU | |
| Molding Method | Rotary Mold with Slide Switching | |
| Product Accuracy | ±0.02mm | |
| Cooling System | Multi-channel Circulating Cooling | |
| Product Cycle | 60–90 Days |
Product Advantages
- Exquisite Appearance Enhanced Functionality
- Dual-Material One-Shot Molding High Efficiency
- Long Mold Life and Stable Use
- Cost Savings
FAQ
Q1: Can the mold achieve a two-color gradient?
A1: Yes, by optimizing the partitions during design.
Q2: What is the mold life?
A2: 650,000–1.15 million molds.
Q3: What is the production cycle?
A3: Typically 60–90 days.
Q4: What is the mold accuracy?
A4: ±0.02mm.
Q5: Do you provide a mold trial service?
A5: Yes, to ensure customer satisfaction.
Customized Services
We offer comprehensive customization services, including dual-color areas, material combinations, mold structure, and surface treatment, to meet individual customer needs.
