1 - 12 Cavities Plastic Injection Molds 600K Cycles Cold Runner Mould
-
Highlight
1 Cavity Plastic Injection Molds
,12 Cavities Plastic Injection Molds
,600K Cycles Cold Runner Mould
-
Product NamePlastic Injection Molds
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
1 - 12 Cavities Plastic Injection Molds 600K Cycles Cold Runner Mould
Cold Runner Injection Mold 1-12 Cavities 600K Cycles
Cold runner injection molds utilize a traditional gate system, offering economical solutions for small to medium-volume production with easy maintenance and modification capabilities.
Product Process
Our streamlined manufacturing process ensures quality and precision:
- Analyze product size and quantity requirements
- CAD design of cavity and optimal gate locations
- Precision CNC machining of cavities and runners
- Assembly of cooling systems and guide components
- Comprehensive mold testing to verify precision and material flow
Technical Specifications
| Parameter | Description |
|---|---|
| Mold Type | Cold runner injection mold |
| Mold Material | P20 H13 |
| Number of Cavities | 1–12 cavities |
| Mold Life | 600,000–1,000,000 cycles |
| Surface Treatment | Polished |
| Applicable Materials | ABS, PS, PP, PC |
| Precision Tolerance | ±0.03mm |
| Cooling System | External circulating water cooling |
| Injection Molding Machine Compatibility | 100T–400T |
| Production Cycle | 40–60 days |
Product Applications
- Small household appliance components
- Plastic parts for daily necessities
- Consumer electronics plastic components
Key Advantages
- Cost-effective solution for small and medium production batches
- Easy maintenance and modification capabilities
- Excellent cavity balance for consistent quality
- Reliable precision with tight tolerances
Frequently Asked Questions
Q: Are cold runner molds suitable for large batches?
A: Not recommended for high-volume production. Hot runners are better suited for large batch quantities.
Q: Is it prone to blockage?
A: Regular mold cleaning effectively prevents blockage issues.
Q: Are cold runners compatible with hot runner products?
A: These are fundamentally different designs and cannot be directly interchanged.
Q: Can the number of cavities be increased?
A: Yes, but must consider the injection molding machine's capacity limitations.
Q: What is the mold lifespan?
A: Standard materials can produce up to one million molds with proper maintenance.
Customized Solutions
We provide tailored cold runner mold solutions for cost-sensitive production, with flexible options for cavity count, dimensions, and material specifications to meet your specific requirements.
