Gas Assisted Injection Molding Services Plastic Parts Mould For Lightweight Hollow Parts
-
Highlight
Chrome Plating Gas Assisted Injection Molding
,Lightweight Plastic Parts Mould
,Hollow Plastic Parts Mould
-
Product NameGas Assisted Injection Molding
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Gas Assisted Injection Molding Services Plastic Parts Mould For Lightweight Hollow Parts
Gas-Assisted Injection Molds for Lightweight Hollow Parts
Gas-assisted injection molds create a hollow structure by injecting gas, reducing part weight, saving material, and improving surface quality.
Process Flow
- Product Analysis to Determine Gas Flow Path
- CAD Design of Gas-Assisted Cavity
- CNC Machining of Cavity and Gas Flow Path
- Installation of Gas Injection System
- Test Mold to Verify Wall Thickness Uniformity
Product Specifications
| Item | Value |
|---|---|
| Mold Type | Gas-Assisted Injection Mold |
| Mold Material | H13, S136 |
| Number of Cavities | 1–6 |
| Mold Life | 600,000–1,000,000 Molds |
| Surface Treatment | Chrome Plating, Polishing |
| Gas Injection | Nitrogen or Air |
| Applicable Materials | PP, PE, ABS, PC |
| Precision Tolerance | ±0.02mm |
| Cooling System | High-Efficiency Water Cooling |
| Production Cycle | 55–75 Days |
Product Applications
- Hollow Handle
- Container Cap
- Plastic Pipe Fittings
Product Advantages
- Material Savings, Cost Reduction
- Part Weight Reduction
- Improved Surface Smoothness
- High-Precision Wall Thickness Control
Frequently Asked Questions
Q1: Is a gas-assisted mold suitable for mass production?
A1: Yes, but requires proper gas path design.
Q2: Does the gas affect strength?
A2: Proper design will not compromise structural strength.
Q3: What is the mold lifespan?
A3: High-quality steel can produce up to one million molds.
Q4: Can it be integrated with a hot runner?
A4: Yes, it can improve efficiency.
Q5: Can it produce complex hollow shapes?
A5: It can use CAE to optimize the gas path.
Customized Service
We can customize gas-assisted molds based on the shape of the hollow product, improving material utilization and product performance.
