P20 H13 S136 Insert Mould 500000 Cycles Auto Parts Moulds Customized
-
Highlight
S136 Insert Mould
,500000 Cycles Auto Parts
,Auto Parts Moulds Customized
-
Product NameInsert Mould
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
P20 H13 S136 Insert Mould 500000 Cycles Auto Parts Moulds Customized
Insert Plastic Injection Molds For Automotive Parts 500000 Cycles
Product Description
Insert molds combine metal and plastic components to enhance structural strength and functionality in manufactured parts.
Process Flow
- Mold Design: Create positioning grooves based on insert shape
- Insert Preparation: Machine metal or functional components
- Mold Manufacturing: Complete cavity, gate, and positioning system
- Mold Assembly Trial: Verify insert positioning and plastic encapsulation
- Optimization and Adjustment: Ensure secure plastic-to-insert bonding
Product Parameters
| Parameter Category | Description |
|---|---|
| Mold Type | Insert Injection Mold |
| Mold Material | P20, H13, S136 |
| Insert Material | Steel, Copper, Aluminum, Ceramic |
| Molding Material | ABS, PA, PC |
| Mold Life | 500,000–1,000,000 cycles |
| Assembly Method | Manual or automatic insert placement |
| Machining Method | CNC, EDM |
| Mold Cycle | 30–45 days |
| Application Industries | Automotive, Electronics, Home Appliances |
| Molding Accuracy | ±0.03mm |
Applications
Widely used in automotive parts, electronic connectors, and home appliance components.
Product Advantages
- Strong bond for improved structural strength
- Integrated molding reduces assembly steps
- Versatile applications across industries
- Compatible with various insert materials
FAQ
Q1: Does the insert have to be metal?
A1: Not necessarily. Specialty materials such as ceramic or rubber can also be used.
Q2: Does insert molding affect efficiency?
A2: Manual placement is inefficient; automation can improve efficiency.
Q3: How strong is the bond?
A3: High-temperature fusion ensures a strong bond that resists fallout.
Q4: What is the mold lifespan?
A4: Up to 500,000–1,000,000 mold cycles.
Customized Services
We support custom inserts and automated placement solutions to meet diverse manufacturing needs.
