4 - 128 Cavities Plastic Injection Molds 1M Cycles Multi Cavity Injection Mold
-
Highlight
4 Cavities Plastic Injection Molds
,128 Cavities Plastic Injection Molds
,1M Cycles Multi Cavity Injection Mold
-
Product NamePlastic Injection Molds
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
RunnerHot Runner\ Cold Runner,cold/hot
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
CavityMulti Cavity,as Per Client's Requirement
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
4 - 128 Cavities Plastic Injection Molds 1M Cycles Multi Cavity Injection Mold
Multi Cavity Plastic Injection Mold 4-128 Cavities 1M Cycles
High Output Stable Quality Mass Production
Product Description
Multi-cavity high-speed injection molds are engineered for large-scale production, utilizing hot runner technology and precision distribution to ensure maximum production capacity and product consistency.
Process Flow
- Mold Design: Based on cavity distribution and hot runner balance
- Material Preparation: High-hardness steel such as H13
- Precision Machining: High-speed CNC and grinding to ensure cavity consistency
- Assembly and Commissioning: Install the hot runner system and calibrate the runner balance
- Mold Trial Optimization: Ensure uniform filling of each cavity
Product Parameters
| Parameter | Description |
|---|---|
| Mold Type | Multi-cavity high-speed injection mold |
| Mold Material | H13, S136 |
| Molding Material | PP, PE, ABS, PC |
| Cavities | 4–128 |
| Mold Life | Over 1 million cycles |
| Hot Runner | Full/Semi-hot runner |
| Mold Cycle Time | 35–50 days |
| Molding Accuracy | ±0.02mm |
| Application Industries | Medical, Packaging, Automotive |
| Cooling Method | High-efficiency water cooling |
Product Applications
Designed for high-volume production of medical consumables, packaging containers, and automotive parts.
Product Advantages
- High production capacity and efficiency
- Excellent product consistency
- Hot runner system reduces material waste
- Long service life, ideal for long-term mass production
Frequently Asked Questions
Q: What is the maximum number of cavities in a multi-cavity mold?
A: 4–128 cavities are common, depending on product size.
Q: Is a hot runner required?
A: High-cavity molds are often used with hot runners.
Q: How is product consistency ensured?
A: Through precision machining and runner balance design.
Q: What is the mold life?
A: High-quality steel molds can reach up to one million cycles.
Customized Services
The number of cavities and runner types can be customized based on production capacity requirements to meet the high-volume production needs of various industries.
