Mirror Polish High Precision Injection Mold 1 - 32 Cavities Custom Injection Molds
-
Highlight
Mirror Polish High Precision Injection Mold
,1 Cavity Custom Injection Molds
,32 Cavities Custom Injection Molds
-
Product NameHigh Precision Injection Mold
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Mirror Polish High Precision Injection Mold 1 - 32 Cavities Custom Injection Molds
High Precision Plastic Injection Mold 1-32 Cavities ±0.01mm Tolerance
High-Precision Injection Mold
Our high-precision mold utilizes advanced five-axis machining and EDM technology, achieving manufacturing tolerances of ±0.01mm for producing exceptionally precise components.
Product Parameters
| Parameter Name | Parameter Description |
|---|---|
| Mold Material | S136 8407 |
| Number of Cavities | 1–32 |
| Product Size Range | 1mm–100mm |
| Injection Molding Machine Capacity | 30T–500T |
| Cooling Method | High-efficiency water cooling |
| Injection Pressure | 100–1800bar |
| Service Life | 500,000–1,000,000 cycles |
| Surface Treatment | Mirror Polish |
| Mold Type | High-Precision Mold |
| Applicable Materials | POM, PA, PC |
Applications
- Micro Gears
- Precision Connectors
- Medical Consumables
- Electronic Sensor Housings
Product Advantages
- Extremely High Dimensional Accuracy (±0.01mm)
- Excellent Surface Finish with Mirror Polish
- High Product Consistency for Mass Production
- Specialized for Micro-Product Manufacturing
Frequently Asked Questions
Q: Can we mass-produce micro parts?
A: Yes, our molds are designed for high-precision mass production of micro components.
Q: Is the mold lifespan shortened with micro parts?
A: No, our premium material selection ensures a long lifespan of 500,000–1,000,000 cycles.
Custom Mold Solutions
We offer customized mold design services, including specialized cooling and gating systems, tailored to your specific part tolerance requirements.
