Gas Assisted Plastic Injection Molds Lightweight Hollow Parts Stronger Structure
-
Highlight
gas assisted plastic injection molds
,high shot life injection molds
,durable plastic injection molds
-
Product MaterialPlastic,ABS+PC
-
GateSide Gate, Sub Gate, Pin Point Gate
-
MaterialPlastic
-
KeywordsPlastic Injection Molds
-
StandardLKM|DME|HASCO
-
ApplicationIndustrial Magnetic Machine
-
Plates4 Plates
-
DescriptionPlastic Injection Mould
-
Mould Life250000-300000shots
-
ColorCustomized
-
Cooling MethodIndirect Cooling
-
RunnerHot Runner\ Cold Runner
-
SurfaceHigh Polishing
-
Injection Machine90 , 120 ,180 ,270 T
-
Mold Time3 ~ 5 Days
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
Gas Assisted Plastic Injection Molds Lightweight Hollow Parts Stronger Structure
Gas Assisted Plastic Injection Molds for Lightweight Hollow Parts with Stronger Structure
Product Process
Gas-assisted injection molds introduce high-pressure nitrogen during the injection process, evenly distributing the molten plastic within the mold cavity to create a hollow structure. This innovative process reduces material usage while significantly improving product strength.
Product Parameters
| Parameter Name | Parameter Description |
|---|---|
| Mold Material | H13, S136 |
| Number of Cavities | 1–8 |
| Product Size Range | 50mm–800mm |
| Injection Molding Machine Tonnage | 150T–3000T |
| Cooling Method | Water + Air |
| Injection Pressure | 70–1600bar |
| Service Life | 100,000–600,000 Cycles |
| Surface Treatment | Polishing, Nitriding |
| Mold Type | Gas-Assisted Mold |
| Applicable Materials | ABS, PP, HDPE |
Applications
- Automobile Door Handles
- Home Appliance Handles
- Pipe Parts
- Furniture Armrests
Advantages
- Hollow Structure for Lightweight Components
- Reduces Raw Material Costs
- Eliminates Shrinkage Marks
- Enhanced Strength and Toughness
FAQ
Q: Can complex hollow parts be produced?
A: Yes, our gas-assisted injection molding is particularly suitable for manufacturing irregular pipe fittings and complex hollow components.
Q: Are high air supply requirements needed?
A: A stable nitrogen supply is sufficient for optimal performance in our gas-assisted molding process.
Customized Molds
We design optimal airway systems based on your part thickness and structural requirements to ensure superior molding results for your specific application.
