High Speed Plastic Injection Tooling 24 Cavity H13 Steel Toy Injection Mold
-
Highlight
High Speed Plastic Injection Tooling
,24 Cavity Toy Injection Mold
,H13 Steel Toy Injection Mold
-
Product NamePlastic Injection Tooling
-
Product MaterialPlastic,Steel,PP,ABS,PS
-
Shaping ModePlastic Injection Mould,Plastic Injection Molding,Compression Mould
-
ProductVehicle Mould,Household Appliance,plastic Injection Mold,injection Machine Mold,Household Product
-
MaterialSTEEL,ps,PP,Steel And Metal,aluminum
-
Mould Life250000-300000shots,200~1 M Available,300,000shots,000 Times
-
RunnerHot Runner\ Cold Runner,cold/hot
-
CavityMulti Cavity,as Per Client's Requirement
-
Mold MaterialNAK80,H13,50#,P20,45#
-
Design SoftwareCAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
-
Mould MaterialP20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 Etc,H13
-
ApplicationHome Appliance,Industrial,Automotive,various Range,Machine
-
CertificationISO9001,FDA,ISO13485
-
Mould BaseNon-Standard Plastic Injection Mould,World Standard,European Standard,LKM.HASCO,HASCO Standard
-
Surface TreatmentSandblasted,Texture,anodizing Black,clear Painting,Polishing
-
Mold Life000 To 1,500000 Shots,000 Shots,100000-1000000,50
-
Mold RunnerHot&Cold Runner You Can Choose,Hot Runner And Code Runner
-
Plastic MaterialPeek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
-
SizeAs Samples/drawings,customized Accepted,Customized Size
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
High Speed Plastic Injection Tooling 24 Cavity H13 Steel Toy Injection Mold
High-Speed Plastic Injection Mold 24-Cavity H13 Steel
High-Speed Injection Mold
High-speed injection molds utilize advanced flow channel design and a highly efficient cooling system, ensuring rapid plastic filling and uniform cooling. The processing incorporates precision milling and wire-cutting techniques to ensure high repeatability.
Product Parameters
| Parameter Name | Parameter Description |
|---|---|
| Mold Material | H13, S136 Steel |
| Number of Cavities | 1–24 |
| Product Size Range | 20mm–400mm |
| Injection Molding Machine Tonnage | 80T–1400T |
| Cooling Method | Water/Air Combination |
| Injection Pressure | 70–1600bar |
| Service Life | 80,000–600,000 Cycles |
| Surface Treatment | Chrome Plating, Polishing, Laser Engraving |
| Mold Type | Two-plate, Three-plate, Hot Runner Mold |
| Applicable Materials | ABS, PC, PP, PA, POM |
Applications
- High-speed Consumer Electronics Housings
- Precision Toy Parts
- Industrial Control Panels
- Lightweight Automotive Parts
Advantages
- Short Production Cycle, High Efficiency
- Durable Mold, Suitable for High-Frequency Use
- High Precision, High Finish Consistency
- Supports Complex Parts and Multi-Cavity Production
FAQ
Q: What is the Production Speed?
A: Optimized cooling and runner design significantly shortens molding cycle times.
Q: What materials are compatible?
A: We offer a wide range of thermoplastic materials, including high-temperature plastics.
Customized Mold Design
We can customize the flow path, cooling, and cavity design based on your part size and production requirements, enabling high-speed and efficient production.
Related Cases
Our services cover all industries and reach all parts of the world.
