High Precision ABS Injection Mould for AC Split Indoor Unit Cover
-
Highlight
ABS injection mold for AC cover
,high precision plastic injection mold
,AC cover mold with tight tolerance
-
File FormatSolidworks,Pro/Engineer,Auto CAD,PDF,JPG
-
InsulationWater ,dust Proof
-
Mold TypeInjection Mold
-
Tolerance±0.01mm
-
Mould MaterialP20/718/738/NAK80/S136
-
Mold SizeCustom
-
ShipmentBy Sea Or Air , Or Express
-
StructureMany Slides And Insert
-
DescriptionPlastic Injection Mould
-
Mould Steel718.2344 .2343. H13.SKD61.NAK80
-
Plastic MaterialABS/PP/PS/PE/PVC/PA6/PA66..et
-
RunnerHot Runner, Cold Runner
-
CertificaROHS ,ISO 9001 ,UL Standard.
-
Prodcut NameInduction Cooker Case
-
Mold Life100,000 - 1,000,000 Shots
-
Place of OriginDongguan, China
-
Brand NameMID MOULD
-
CertificationISO9001:2015 Certificate, export standard compliant
-
Minimum Order Quantity1 set
-
PriceUSD $3,000–$50,000 per set (depending on complexity)
-
Packaging DetailsWooden case + anti-rust oil + protective film + packing list
-
Delivery Time25–45 working days (longer for complex tools)
-
Payment Terms50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
-
Supply Ability20–35 sets per month, depending on structure
High Precision ABS Injection Mould for AC Split Indoor Unit Cover
High Precision ABS Injection Mould for AC Indoor Cover
Plastic Injection Molds for Air Conditioner Indoor Unit Housing
The air conditioner indoor unit housing mold is manufactured using plastic injection molding technology. The mold cavity is precisely machined with CNC equipment, and engineering plastics such as ABS, HIPS, or modified PP are melted at high temperature and injected into the mold cavity. After cooling and demolding, the final housing product is obtained.
Process Workflow
- Mold Design & CAE Analysis → Optimize flow channels, cooling system, and structural strength
- Mold Steel Selection & Processing → Use high-hardness steels (H13, S136) to ensure long service life
- Injection Molding → Control temperature, pressure, and cooling cycle to ensure dimensional accuracy and surface quality
- Post-Treatment → Includes trimming, painting, silk-screen printing, UV coating, etc. to enhance appearance and durability
Product Specifications
| Parameter | Specification |
|---|---|
| Mold Type | Plastic Injection Mold |
| Application | Air Conditioner Indoor Unit Housing |
| Material Options | ABS / HIPS / Modified PP |
| Mold Life | 500,000 – 1,000,000 shots |
| Mold Steel | H13 / S136 / P20 |
| Molding Method | Hot runner or cold runner injection |
| Surface Finish | Polishing, painting, UV coating |
| Tolerance | ±0.05 mm |
| Mold Cavities | Single / Multi-cavity (customizable) |
| Lead Time | 35 – 60 days (depending on complexity) |
Product Applications
This mold is mainly used for producing indoor unit housings for residential and commercial air conditioners, widely applied in:
- Homes & apartments
- Offices & shopping malls
- Hotels & public facilities
Product Advantages
- High Precision Molding: Stable dimensions and reliable assembly
- Aesthetic Appearance: Glossy, matte, or textured finishes available
- Durability: Excellent toughness, anti-aging, and UV resistance
- High Efficiency: Automated injection molding for mass production
- Flexible Customization: Tailor-made designs based on client needs
Frequently Asked Questions
Q1: What is the service life of the mold?
A1: Typically between 500,000–1,000,000 shots, depending on steel material and maintenance.
Q2: Can the air conditioner housing be produced in different colors?
A2: Yes, by adding masterbatch or applying painting processes.
Q3: How long is the mold development cycle?
A3: Usually 35–60 days, depending on mold complexity.
Q4: Do you support small batch trial production?
A4: Yes, we provide trial samples for customer testing and verification.
Customized Mold Services
We provide one-stop custom mold solutions:
- Appearance design support (aligned with brand style)
- Structural optimization (lightweight design, enhanced heat dissipation)
- Rapid prototyping & trial molding
- Mass production & after-sales mold maintenance
- Exclusive logo & customized exterior design
